Festo DHEB Series Bellows Gripper

Single-acting bellows gripper with upwards or downwards actuating directions available.

Select your options below…

{{ option.description }}
"{{ option.noLongerAvailable }}" is no longer a valid option. Please choose from the current set of options.
Need help? Call one of our engineers at 1-802-880-3123. We’re open 8:00 am to 5:30 pm ET.
Request pricing below.
${{ calcCost | formatCurrency }} per {{ calcQuantity }} (${{ unitPrice | formatCurrency }} each) per {{ boxQuantity }} (${{ unitPrice | formatCurrency }} each)
Configured Part Number: {{ calcPartNumber }}
Alternate Part Numbers: {{pn}}
{{pn}}
{{ calcAvailability }}
Learn more about this configuration...
Request Quick Quote
Get Business Financing!
Payments as low as ${{monthlyPayments}}/mo
Highlights...

Features

  • 11 sizes for gripping diameter from 8 to 63mm
  • Bellows upwards or downwards direction of movement
  • EPDM or silicone bellow materials available
    • Silicone is food-safe
  • Air connection on the side or from above
  • Single-acting gripper function

The Festo DHEB is a series of bellows grippers with 11 gripping diameter sizes available from 8 to 63mm. The DHEB is ideal for use applications that require gentle internal gripping of fragile workpieces. This series is available with two material options: EPDM or silicone. The silicone material construction provides a food-safe option, as well as having a higher operating temperature range than the EPDM. The EPDM material option contains a higher friction coefficient than the silicone, as well as minimal marking on high-gloss parts. The choice of an upwards or downwards actuating directions for the bellows are available.
