Festo DZF Series Flat Cylinder

Extremely flat design with 1/2 to 2-1/2in non-rotating oval piston, and adjustable cushioning.

Select your options below…

{{ option.description }}
"{{ option.noLongerAvailable }}" is no longer a valid option. Please choose from the current set of options.
Need help? Call one of our engineers at 1-802-880-3123. We’re open Mo-Th 8am to 5:30pm. Fr 8am to 5pm ET.
Request pricing below.
${{ calcCost | formatCurrency }} per {{ calcQuantity }} (${{ unitPrice | formatCurrency }} each) per {{ boxQuantity }} (${{ unitPrice | formatCurrency }} each)
Configured Part Number: {{ calcPartNumber }}
Alternate Part Numbers: {{pn}}
{{pn}}
{{ calcAvailability }}
Learn more about this configuration...
Request Quick Quote
Get Business Financing!
Payments as low as ${{monthlyPayments}}/mo
Highlights...

Features

  • Double-acting
  • 1/2 to 2-1/2in piston size
  • 1/2 to 12in stroke
  • Moment capacity up to 13.3 lbf-in
  • Magnetic piston for position sensing
  • Elastic cushioning rings/plates at both ends
  • Protection against rotation

The Festo DZF Series Flat Cylinder is a double-acting cylinder with adjustable cushioning and an oval piston that provides an anti-rotation feature. It is designed for high packing density with block mounting assemblies. The piston is magnetic for position sensing and comes in three types—single-ended, through, and hollow through—to meet application requirements.
