Festo ELGE Series Toothed Belt Axis Unit

Electromechanical axis with toothed belt, recirculating ball bearing guide, and up to 800mm working stroke.

Select your options below…

{{ option.description }}
"{{ option.noLongerAvailable }}" is no longer a valid option. Please choose from the current set of options.
Need help? Call one of our engineers at 1-802-880-3123. We’re open Mo-Th 8am to 5:30pm. Fr 8am to 5pm ET.
Request pricing below.
${{ calcCost | formatCurrency }} per {{ calcQuantity }} (${{ unitPrice | formatCurrency }} each) per {{ boxQuantity }} (${{ unitPrice | formatCurrency }} each)
Configured Part Number: {{ calcPartNumber }}
Alternate Part Numbers: {{pn}}
{{pn}}
{{ calcAvailability }}
Learn more about this configuration...
Request Quick Quote
Get Business Financing!
Payments as low as ${{monthlyPayments}}/mo
Highlights...

Features

  • Size 35
  • Stepper motor ST
  • 50 to 800mm stroke
  • ±0.1 repetition accuracy
  • 32 to 122°F (0 to 50°C) ambient temperature
  • Digital I/O and IO-Link control types
  • Horizontal mounting position
  • IP20 protection rating

The Festo ELGE Series Toothed Belt Axis Unit is part of the simplified motion series and offers smooth running behavior for simple movement and positioning tasks. These integrated actuators are the perfect solution when looking for facilities that want an electric alternative for very simple movement tasks but don't want the complex commissioning process of traditional electric drive systems. It features built-in end-position sensing and includes two control types as a standard: digital I/O (DIO) and IO-Link. The ELGE series operates on a plug-and-work principle and does not require an external servo drive or control cabinet for installation.

Applications

  • Food and packaging
  • Electrical Automation
  • Shifting and transfer applications
  • Simple movements between two end positions
