Festo FRM-H-3/4-D-MIDI Branching Module

Branching module with G3/4 pneumatic connection, With integrated non-return function, and Grid dimension 55mm (without connecting plates). View other configurations.

$110.04
Add to NetSuite
Part Numbers
  • FRM-H-3/4-D-MIDI
  • 162793
Highlights...

Features

  • Optional mounting position
  • Branching module design
  • 991511 symbol
  • 5000L2 standard nominal flow rate in main flow direction 1->2
  • Compressed air to ISO 8573-1:2010 [7:-:-] operating medium
  • Inert gases operating medium
  • 2 - Moderate corrosion stress corrosion resistance class cRC
  • VDMA24364-B1/B2-L lABS (PWIS) conformity
  • Compressed air to ISO 8573-1:2010 [7:-:-] air purity class at output
  • Inert gases air purity class at output
  • -10GC media temperature
  • 60GC media temperature
  • 476G product weight
  • RoHS-compliant note on materials
  • Die-cast aluminium material housing
  • 0.2BAR to 16BAR operating pressure
  • -10GC ambient temperature to 60GC ambient temperature
  • -10GC to 60GC storage temperature
  • Pneumatic connection g3/4 , port 1
  • Pneumatic connection g3/4 , port 2
  • Pneumatic connection g1/2 , port 3
  • Pneumatic connection g1/4 , port 4
