Festo PZVT-AUT Reset Module

Features

• Mechanical sequence counter with pneumatic drive design
• 0.1BAR switch-off pressure
• 1.6BAR switch-on pressure
• 50L2 standard nominal flow rate
• 0.2S adjustable delay time
• 2S adjustable delay time
• 200MS pause duration for reset
• ± 0.3 s repetition accuracy of time setting
• Compressed air to ISO 8573-1:2010 [7:4:4] operating medium
• Lubricated operation not possible note on operating and pilot medium
• VDMA24364-B1/B2-L lABS (PWIS) conformity
• IP54 degree of protection
• With protective cap and panel frame degree of protection
• To IEC 60529 degree of protection
• 50G product weight
• Front panel mounting type of mounting
• RoHS-compliant note on materials
• ABS material housing
• 2BAR to 6BAR operating pressure
• -15GC ambient temperature to 60GC ambient temperature
• Pneumatic connection female thread M5
