Festo VPWS-2.2-B-6-PC15-3-V Proportional Directional Control Valve

Subbase directional control valve with 15mm cartridge pneumatic connection and 2.2mm width and 0 to 3bar pressure range. View other configurations.

$181.83
Part Numbers
  • VPWS-2.2-B-6-PC15-3-V
  • 8074074
Highlights...

Features

  • 2.2MM nominal size
  • Electric type of actuation
  • Soft sealing principle
  • Optional mounting position
  • Directly actuated poppet valve design
  • Mechanical spring type of reset
  • Direct type of piloting
  • Non-reversible flow direction
  • 995954 symbol
  • 2/2 proportional directional control valve, closed valve function
  • 0MPA operating pressure
  • 0.3MPA operating pressure
  • 0BAR operating pressure
  • 3BAR operating pressure
  • 0.3MPA nominal operating pressure
  • 3BAR nominal operating pressure
  • 43.5PSI nominal operating pressure
  • 3BAR burst pressure
  • 30BAR burst pressure
  • 435PSI burst pressure
  • 46L2 standard flow rate
  • 56L2 standard flow rate
  • 16MA hysteresis
  • 18HZ max. switching frequency
  • 0MA current regulating range
  • 200MA current regulating range
  • 2.5W max. electrical power consumption
  • 60.5OHM coil resistance r20
  • 100% (see assembly instructions) duty cycle
  • ISO 15001 report surface cleanliness according to standard
  • 550MGM maximum impurity level for hydrocarbons
  • 1 - Low corrosion stress corrosion resistance class cRC
  • VDMA24364 zone III lABS (PWIS) conformity
  • Inert gases medium
  • Air medium
  • Oxygen medium
  • Lubricated operation not possible note on the medium
  • Maximum particle size 10 µm note on the medium
  • 5GC media temperature
  • 50GC media temperature
  • IP60 degree of protection
  • IP65 with suitable plug note on degree of protection
  • In assembled state note on degree of protection
  • 23G product weight
  • Cable electrical connection 1, connection type
  • Open end electrical connection 1, connector system
  • 2 electrical connection 1, number of connections/cores
  • 0.07MM cable length
  • 0.08MM cable length
  • On sub-base type of mounting
  • Plug-in type of mounting
  • With accessories type of mounting
  • RoHS-compliant note on materials
  • FPM material seals
  • High-alloy steel material housing
  • 5GC ambient temperature to 50GC ambient temperature
  • -40GC to 80GC storage temperature
  • Pneumatic connection cartridge 15 mm , port 1
  • Pneumatic connection cartridge 7.2 mm , port 2
