Festo YSRW-7-10 Shock Absorber

Features

• 7 size
• 10MM stroke
• Self-adjusting cushioning
• Soft characteristic curve cushioning
• Optional mounting position
• Without position detection
• 991495 symbol
• 3M/S max. impact speed
• 0.2S reset time at room temperature
• 1S reset time at min. ambient temperature
• Pushing mode of operation
• Single-acting mode of operation
• 2 - Moderate corrosion stress corrosion resistance class cRC
• VDMA24364-B2-L lABS (PWIS) conformity
• -10GC ambient temperature
• 80GC ambient temperature
• 10MM cushioning length
• 300N max. stop force
• 2.5J max. energy consumption per stroke
• 15000J max. energy consumption per hour
• 0.01J max. residual energy
• 1.2N reset force
• 10N min. insertion force
• 18G product weight
• 5KG load range
• Via lock nut type of mounting
• RoHS-compliant note on materials
• NBR material seals
• High-alloy steel material housing
• High-alloy steel material piston rod
