Aventics SWN-SA-06-010-M10X1 Pneumatic Linear Actuator

Mini cylinder, Screw-in cylinder. View other configurations.

$33.88
Part Numbers
  • SWN-SA-06-010-M10X1
  • 0822406901
Highlights...

Features

  • Bore Size: 6 mm
  • Cushioning: Elastic cushioning
  • Cylinder Function: single-acting
  • Environmental requirements: Industry standard
  • Industry: Industrial
  • Magnetic piston: Piston without magnet
  • Max Working Pressure: 8 bar
  • Piston force extending: 15 N
  • Piston rod modification: single
  • Piston rod thread type: External thread
  • Scraper Type: Standard Industry Scraper
  • Stroke Length: 10 mm
  • Dimension: 1.38x0.43x0.43 (inches)
View other configurations.
AVENTICS Screw-in cylinder, Series SWN 0822406901
