Aventics CCI-DA-040-0050-0071224110000200000000-B Pneumatic Linear Actuator

multi-position cylinder, Compact cylinder, ISO 21287, Piston rod cylinders, ISO cylinder, Standard cylinders. View other configurations.

$188.21
Part Numbers
  • CCI-DA-040-0050-0071224110000200000000-B
  • R422001336
Highlights...

Features

  • Bore Size: 40 mm
  • Compressed air connection: G 1/8
  • Cushioning: Elastic cushioning
  • Cylinder Function: Double-acting
  • Environmental requirements: Industry standard, ATEX optional
  • Industry: Industrial
  • Magnetic piston: Piston with magnet
  • Max Working Pressure: 10 bar
  • Piston force extending: 792 N
  • Piston force retracting: 720 N
  • Piston rod modification: non-rotating, with front plate
  • Piston rod thread: M8
  • Piston rod thread type: Internal thread
  • Scraper Type: Standard Industry Scraper
  • Stroke Length: 50 mm
  • Dimension: 4.33x1.97x1.97 (inches)
View other configurations.
AVENTICS Compact cylinder ISO 21287, Series CCI R422001336
