Aventics CCL-DA-063-0200-IS-0210032211AB00000-BAS Pneumatic Linear Actuator

Compact cylinder, ISO 21287, Piston rod cylinders, suitable for use in food processing, ISO cylinder, Standard cylinders. View other configurations.

$347.72
Part Numbers
  • CCL-DA-063-0200-IS-0210032211AB00000-BAS
  • R480060041
Highlights...

Features

  • Bore Size: 63 mm
  • Compressed air connection: G 3/8
  • Cushioning: Pneumatic adjustable cushioning
  • Cylinder Function: Double-acting
  • Environmental requirements: Industry standard, suitable for use in food processing, ATEX optional, High corrosion
  • Industry: Industrial
  • Magnetic piston: Piston with magnet
  • Max Working Pressure: 10 bar
  • Piston force extending: 1964 N
  • Piston force retracting: 1766 N
  • Piston rod modification: single
  • Piston rod thread: M16x1,5
  • Piston rod thread type: External thread
  • Scraper Type: Standard Industry Scraper
  • Stroke Length: 200 mm
  • Dimension: 15.75x2.95x2.95 (inches)
View other configurations.
AVENTICS ISO 15552, series CCL-IS R480060041
