Aventics CCL-DA-100-0160-IS-0230040211AB00000-BAS Pneumatic Linear Actuator

Piston rod cylinders, Standard cylinders, suitable for use in food processing, ISO 21287, Compact cylinder, ISO cylinder. View other configurations.

Call for pricing
Part Numbers
  • CCL-DA-100-0160-IS-0230040211AB00000-BAS
  • R480193191
Highlights...

Features

  • Bore Size: 100 mm
  • Compressed air connection: G 1/2
  • Cushioning: Pneumatically
  • Cylinder Function: Double-acting
  • Environmental requirements: Industry standard, suitable for use in food processing, ATEX optional, High corrosion
  • Industry: Industrial
  • Magnetic piston: Piston with magnet
  • Max Working Pressure: 10 bar
  • Piston force retracting: 4639 N
  • Piston rod modification: through
  • Piston rod thread: M20x1,5
  • Piston rod thread type: External thread
  • Scraper Type: Standard Industry Scraper
  • Stroke Length: 160 mm
  • Dimension: 25.98x4.72x4.72 (inches)
View other configurations.
AVENTICS ISO 15552, series CCL-IS R480193191
