Aventics MNI-DA-20-0250-D-01-01-1-00-000-00 Pneumatic Linear Actuator

Mini cylinder, Standard cylinders, Round cylinder, ISO cylinder, ISO 6432, Piston rod cylinders. View other configurations.

$118.70
Part Numbers
  • MNI-DA-20-0250-D-01-01-1-00-000-00
  • 0822233009
Highlights...

Features

  • Bore Size: 20 mm
  • Compressed air connection: G 1/8
  • Cushioning: Pneumatic adjustable cushioning
  • Cylinder Function: Double-acting
  • Environmental requirements: Industry standard, ATEX optional
  • Industry: Industrial
  • Magnetic piston: Piston without magnet
  • Max Working Pressure: 10 bar
  • Piston force extending: 198 N
  • Piston force retracting: 166 N
  • Piston rod modification: single
  • Piston rod thread: M8
  • Piston rod thread type: External thread
  • Scraper Type: Standard Industry Scraper
  • Stroke Length: 250 mm
  • Dimension: 14.96x1.38x1.38 (inches)
View other configurations.
AVENTICS Mini cylinder, Series MNI 0822233009
