Aventics MNI-DA-16-0500-D-31-23-1-00-000-00 Pneumatic Linear Actuator

ISO 6432, Mini cylinder, Round cylinder, Piston rod cylinders, ISO cylinder, Standard cylinders. View other configurations.

Call for pricing
Part Numbers
  • MNI-DA-16-0500-D-31-23-1-00-000-00
  • R480680354
Highlights...

Features

  • Bore Size: 16 mm
  • Compressed air connection: M5
  • Cushioning: Pneumatic adjustable cushioning
  • Cylinder Function: Double-acting
  • Environmental requirements: Industry standard
  • Industry: Industrial
  • Magnetic piston: Piston with magnet
  • Max Working Pressure: 10 bar
  • Piston force extending: 127 N
  • Piston force retracting: 110 N
  • Piston rod modification: non-rotating
  • Piston rod thread: M6
  • Piston rod thread type: External thread
  • Scraper Type: Standard Industry Scraper
  • Stroke Length: 500 mm
View other configurations.
AVENTICS Mini cylinder, Series MNI R480680354
