Aventics KHZ-DA-016-0050-M-NR Pneumatic Linear Actuator

Piston rod cylinders, Short-stroke cylinder. View other configurations.

$137.00
Effective March 12th, Aventics has added a 7.5% surcharge for all of their products. The surcharge will appear as a separate line item on each sales order.
Part Numbers
  • KHZ-DA-016-0050-M-NR
  • 0822010817
Highlights...

Features

  • Bore Size: 16 mm
  • Compressed air connection: M5
  • Cushioning: Elastic cushioning
  • Cylinder Function: Double-acting
  • Environmental requirements: Industry standard
  • Industry: Industrial
  • Magnetic piston: Piston with magnet
  • Max Working Pressure: 10 bar
  • Piston force extending: 127 N
  • Piston force retracting: 95 N
  • Piston rod modification: non-rotating
  • Piston rod thread type: Internal thread
  • Scraper Type: Standard Industry Scraper
  • Stroke Length: 50 mm
  • Dimension: 3.94x1.38x1.18 (inches)
View other configurations.
AVENTICS Short-stroke cylinder, Series KHZ 0822010817
