Aventics SN2-R2-K03P-240 27 OHM Proximity Sensor

Heat resistant, Proximity sensor. View other configurations.

$97.42
Part Numbers
  • SN2-R2-K03P-240 27 OHM
  • 0830100317
Highlights...

Features

  • Cable Length: 3 m
  • Cylinder series: TRB, PRA, ITS, MNI, CSL-RD, ICM, RPC, TRR, FLT, CVI
  • Electrical Connection Type 2: without wire end ferrule, tin-plated
  • Industry: Industrial
  • Number of Poles 2: 2-pin
  • Output Signal: Reed
  • Protection: Protected against polarity reversal
  • Protection class: IP67
  • Supply voltage AC max.: 240 V AC
  • Supply voltage DC max.: 60 V DC
  • Dimension: 4.13x3.94x1.57 (inches)
View other configurations.
AVENTICS Sensor, Series SN2 0830100317
