Aventics CON-RD-MS-M8-3-10000-PVC-OW-3 Round Plug Connector

View other configurations.

Call for pricing
Part Numbers
  • CON-RD-MS-M8-3-10000-PVC-OW-3
  • 8946203622
Highlights...

Features

  • Cable Exit 1: straight
  • Cable Length: 10 m
  • Coding: A-coded
  • Electrical Connection: M8x1
  • Electrical Connection Type: Plug
  • Electrical Connection Type 2: open cable ends
  • Industry: Industrial
  • Max Ambient Temperature: 80 °C
  • Min Ambient Temperature: -25 °C
  • Number of Lines: 3
  • Number of Poles: 3-pin
  • Operating Voltage: 30 V AC/DC
  • Protection class: IP67
  • Shielding: unshielded
  • Dimension: 6.69x7.36x1.50 (inches)
View other configurations.
AVENTICS Round plug connector, Series CON-RD 8946203622
