Aventics ED07-000-060-420-2M12B Proportional Pneumatic Valve

E/P valve, Proportional pressure regulator, Pressure regulator, Proportional valve, E/P pressure control valve. View other configurations.

Call for pricing
Part Numbers
  • ED07-000-060-420-2M12B
  • 5610264810
Highlights...

Features

  • Actuating control: Analog
  • Certifications: CE declaration of conformity
  • Control Type: Directly controlled
  • Current consumption max.: 1400 mA
  • DC operating voltage: 24 V
  • EP Function: Air exhaust
  • Flow L M: 1300 l/min
  • Hysteresis: < 0,03 bar
  • Industry: Industrial
  • Input Signal: 4 ... 20 mA
  • Max Working Pressure: 8 bar
  • Output Signal: Analog, Switch output
  • Protection class: IP65
  • Regulation Range: 6 bar
  • Regulation Range min.: 0 bar
  • Signal connection size: M12
  • Version Regulator: Poppet valve
  • Dimension: 12.76x6.38x6.26 (inches)
View other configurations.
AVENTICS E/P pressure regulator, Series ED07 5610264810
