Aventics DO30-3/2NC-CNOM-024DC Electric and Pneumatic Actuated Directional Valve

Poppet valve, Single valve. View other configurations.

$80.99
Part Numbers
  • DO30-3/2NC-CNOM-024DC
  • 0820019526
Highlights...

Features

  • Activation: Electrically
  • Compatibility index: 15
  • Compressed air connection: CNOMO
  • Compressed air connection output: CNOMO
  • Electrical Connection 2: EN 175301-803, form A
  • Flow L M: 68 l/min
  • Housing Material: Plastic
  • Industry: Industrial
  • Manual Override: without detent
  • Max Working Pressure: 10 bar
  • Min Working Pressure: 0 bar
  • Operating Voltage: 24 V DC
  • Scale size: DO30
  • Seat Seal Type: Soft seal
  • Switching principle: 3/2, with spring return
  • Valve Function: NC
  • Wattage: 4.5 W
  • Dimension: 2.17x1.18x1.97 (inches)
View other configurations.
AVENTICS 3/2-directional valve, Series DO30 0820019526
