Aventics VR04-4/3EC-LEV Electric and Pneumatic Actuated Directional Valve

Plate connection, Poppet valve, Single valve. View other configurations.

Call for pricing
Part Numbers
  • VR04-4/3EC-LEV
  • 5630181100
Highlights...

Features

  • Activation: Mechanical
  • Actuating element: Hand lever, with detent
  • Compressed air exhaust: G 1/8
  • Flow L M: 300 l/min
  • Housing Material: Die cast zinc
  • Industry: Industrial
  • Max Working Pressure: 10 bar
  • Min Working Pressure: 0 bar
  • Seat Seal Type: Soft seal
  • Valve Function: Exhausted Center
  • Dimension: 4.13x2.01x2.68 (inches)
View other configurations.
AVENTICS 4/3-directional valve, Series 563 018 5630181100
