Aventics CON-RD-MS-M12-4-0600-PUR-FS-M8-3-FS-M8-3 Y-Plug Connector

Features

• Cable Exit 1: straight
• Cable Exit 2: straight
• Cable Length: 0.6 m
• Coding: A-coded
• Coding 2: A-coded
• Electrical Connection: M12x1
• Electrical Connection 2: M8x1
• Electrical Connection Type: Plug
• Electrical Connection Type 2: Socket
• Industry: Industrial
• Max Ambient Temperature: 80 °C
• Min Ambient Temperature: -25 °C
• Number of Lines: 3
• Number of Poles: 4-pin
• Number of Poles 2: 3-pin
• Operating Voltage: 48 V AC/DC
• Protection class: IP67
• Shielding: unshielded
• Dimension: 9.45x9.45x0.79 (inches)
