Aventics PRA-DA-125-0100-0322119100000000000000-B Pneumatic Linear Actuator

ISO cylinder, Piston rod cylinders, ISO 15552, Profile cylinder, Standard cylinders. View other configurations.

$1,050.82
Part Numbers
  • PRA-DA-125-0100-0322119100000000000000-B
  • R481602123
Highlights...

Features

  • Bore Size: 125 mm
  • Compressed air connection: G 1/2
  • Cushioning: Pneumatic adjustable cushioning
  • Cylinder Features: Bellows
  • Cylinder Function: Double-acting
  • Environmental requirements: Industry standard
  • Industry: Industrial
  • Magnetic piston: Piston with magnet
  • Max Working Pressure: 10 bar
  • Piston force extending: 7725 N
  • Piston force retracting: 7220 N
  • Piston rod modification: single
  • Piston rod thread: M27x2
  • Piston rod thread type: External thread
  • Scraper Type: Standard Industry Scraper
  • Stroke Length: 100 mm
View other configurations.
AVENTICS Profile cylinder ISO 15552, PRA series R481602123
