Aventics PM1-M3-F001-002-160-M12X1-NONE Pressure Switch

Pressure sensor. View other configurations.

$215.49
Part Numbers
  • PM1-M3-F001-002-160-M12X1-NONE
  • R412010720
Highlights...

Features

  • Compressed air connection: Ø 5x1,5
  • Compressed air connection type: Flange with O-ring
  • Industry: Industrial
  • Mounting position: Any
  • Overpressure Protection: 80 bar
  • Protection class: IP65
  • Switching pressure max.: 16 bar
  • Switching pressure min.: 0.2 bar
  • Dimension: 3.62x2.83x2.36 (inches)
View other configurations.
AVENTICS Pressure Switches, Series PM1 R412010720
