Aventics PG1-ROB-R018-STD-D40P(0-1,6)BLENDE 0,3 Pressure Gauge

Features

• Background color: White
• Compressed air connection: R 1/8
• Display range max.: 1.6 bar
• Display range min.: 0 bar
• Housing Material: Acrylonitrile butadiene styrene
• Industry: Industrial
• Manometer housing diameter: 40 mm
• Max Ambient Temperature: 60 °C
• Max Working Pressure: 1.6 bar
• Min Ambient Temperature: -40 °C
• Pressure Gauge Grade: 2,5
• Range of application max.: 1.2 bar
• Range of application min.: 0 bar
• Scale value: 0.1
• Unit primary scale: bar
• Version Manometer: Bourdon tube pressure gauge, Back port
• Dimension: 1.85x1.69x1.89 (inches)
