Aventics SN2-R2-M008-030 Proximity Sensor

Proximity sensor, Heat resistant. View other configurations.

$50.15
Part Numbers
  • SN2-R2-M008-030
  • 0830100465
Highlights...

Features

  • Cylinder series: TRB, PRA, ITS, MNI, CSL-RD, ICM, RPC, TRR, FLT, CVI
  • Electrical Connection 2: M8
  • Electrical Connection Type 2: Plug
  • Industry: Industrial
  • LED color: Yellow
  • Number of Poles 2: 2-pin
  • Output Signal: Reed
  • Protection: Protected against polarity reversal
  • Protection class: IP67
  • Supply voltage AC max.: 30 V AC
  • Supply voltage DC max.: 36 V DC
  • Dimension: 1.18x0.98x0.98 (inches)
View other configurations.
AVENTICS Sensor, Series SN2 0830100465
