Aventics R432039321 Pneumatic Linear Actuator

View other configurations.

Call for pricing
Part Numbers
  • R432039321
  • R432039321
Highlights...

Features

  • Bellow Cylinder type: Flexible rolling bellow
  • Compressed air connection: 1/8 NPT
  • Cylinder Function: Single-acting, retracted without pressure
  • Force max.: 2300 N
  • Force min.: 1610 N
  • Industry: Industrial
  • Installation height max.: 38 mm
  • Installation height min.: 109.22 mm
  • Material bellow: Chloroprene rubber
  • Material Frontcover: Polyamide fiber-glass reinforced
  • Max Working Pressure: 8 bar
View other configurations.
AVENTICS Rolling bellow, series BRB - inch R432039321
