Aventics CON-VP-F_C-2+E-YE-Z-3000-PVC-OW-3 Valve Plug Connector

View other configurations.

Call for pricing
Part Numbers
  • CON-VP-F_C-2+E-YE-Z-3000-PVC-OW-3
  • 1834484204
Highlights...

Features

  • Cable Exit 1: angled
  • Cable Length: 3 m
  • Electrical Connection: form C
  • Electrical Connection Type: Socket
  • Electrical Connection Type 2: open cable ends
  • Industry: Industrial
  • Max Ambient Temperature: 80 °C
  • Min Ambient Temperature: -20 °C
  • Number of Lines: 3
  • Number of Poles: 2+E
  • Number of Poles 2: 3-pin
  • Operating Voltage: 24 V AC/DC
  • Protection class: IP67
  • Shielding: unshielded
  • Dimension: 8.27x8.27x0.79 (inches)
View other configurations.
AVENTICS Valve plug connector, series CON-VP 1834484204
