Aventics CON-VP-F_CI-4-YE-V-5000-PVC-OW-3 Valve Plug Connector

View other configurations.

$33.11
Effective March 12th, Aventics has added a 7.5% surcharge for all of their products. The surcharge will appear as a separate line item on each sales order.
Part Numbers
  • CON-VP-F_CI-4-YE-V-5000-PVC-OW-3
  • R412024834
Highlights...

Features

  • Cable Exit 1: angled
  • Cable Length: 5 m
  • Electrical Connection: form C, industry
  • Electrical Connection Type: Socket
  • Electrical Connection Type 2: open cable ends
  • Industry: Industrial
  • Max Ambient Temperature: 90 °C
  • Min Ambient Temperature: -25 °C
  • Number of Lines: 3
  • Number of Poles: 4-pin
  • Number of Poles 2: 3-pin
  • Operating Voltage: 24 V AC/DC
  • Protection class: IP65
  • Shielding: unshielded
  • Dimension: 6.69x6.69x0.79 (inches)
View other configurations.
AVENTICS Valve plug connector, series CON-VP R412024834
