Aventics V740-5/2DP-07 Electric and Pneumatic Actuated Directional Valve

Single valve, Poppet valve, Diaphragm poppet valve. View other configurations.

Call for pricing
Part Numbers
  • V740-5/2DP-07
  • 5717410000
Highlights...

Features

  • Activation: Pneumatically
  • Compressed air exhaust: M14x1
  • Flow L M: 700 l/min
  • Housing Material: Polyoxymethylene
  • Industry: Industrial
  • Manual Override: with detent
  • Max Working Pressure: 10 bar
  • Min Working Pressure: 1.5 bar
  • Seat Seal Type: Soft seal
  • Valve Pilot: Internal
  • Dimension: 7.80x3.46x1.97 (inches)
View other configurations.
AVENTICS 5/2-directional valve, Series 740 5717410000
