Sick PBT-RB016SM2SESULA0V Pressure Sensor

Features

• Gauge pressure pressure type
• Bar pressure unit
• 0 bar to 16 bar measuring range
• ≤ ± 1 % of the span accuracy
• ≤ ± 0.5 %, of the span non-linearity
• M20 x 1.5 process connection
• Standard pressure port
• –30 °c to +100 °c process temperature
• Stainless steel seal
• 0 v to 5 v, 3-wire output signal
• L-connector acc. to DIN 175301-803 a connection type
• Ip65 enclosure rating
• 8 v DC to 30 v DC supply voltage
• Shock resistance 20 g specialty
