Aventics RPC-DA-050-0320-13-1-2-BAS Pneumatic Linear Actuator

Piston rod cylinders, Round cylinder. View other configurations.

$210.63
Part Numbers
  • RPC-DA-050-0320-13-1-2-BAS
  • R412020758
Highlights...

Features

  • Bore Size: 50 mm
  • Compressed air connection: G 1/4
  • Cushioning: Pneumatic adjustable cushioning
  • Cylinder Function: Double-acting
  • Environmental requirements: Industry standard, ATEX optional
  • Industry: Industrial
  • Magnetic piston: Piston with magnet
  • Max Working Pressure: 10 bar
  • Piston force extending: 1235 N
  • Piston force retracting: 1035 N
  • Piston rod modification: single
  • Piston rod thread: M16x1,5
  • Piston rod thread type: External thread
  • Scraper Type: Standard Industry Scraper
  • Stroke Length: 320 mm
  • Dimension: 20.08x2.36x2.48 (inches)
View other configurations.
AVENTICS Round cylinder, Series RPC R412020758
