Aventics AV05-5/3EC-VT00-024VDC-LOC Electric and Pneumatic Actuated Directional Valve

Single valve, Spool valve, Plate connection, Base plate valve. View other configurations.

Aventics AV05-5/3EC-VT00-024VDC-LOC Electric and Pneumatic Actuated Directional Valve — Aventics-AV05-5/3EC-VT00-024VDC-LOC

Call for pricing

Part Numbers

AV05-5/3EC-VT00-024VDC-LOC
R422103321

Highlights...

AV05-5/3EC-VT00-024VDC-LOC
By Aventics
FREE Shipping on orders of $1,000 or more
Usually ships in 2 weeks

Features

Activation: Electrically
Flow L M: 650 l/min
Housing Material: Polyamide fiber-glass reinforced
Industry: Industrial
Manual Override: with detent
Max Working Pressure: 10 bar
Min Working Pressure: -0.9 bar
Operating Voltage: 24 V DC
Seat Seal Type: Soft seal
Switching principle: 5/3, exhausted center
Valve Function: Exhausted Center
Valve Pilot: External
Voltage tolerance: -10% / +10%
Wattage: 0.55 W

View other configurations.

AVENTICS 5/3-directional valve, Series AV05 R422103321
