Aventics CD12-5/2XX-DO-M022-M022-G018-S Electric and Pneumatic Actuated Directional Valve

Spool valve, Single valve. View other configurations.

Call for pricing
Part Numbers
  • CD12-5/2XX-DO-M022-M022-G018-S
  • R412013344
Highlights...

Features

  • Activation: Pneumatically
  • Compressed air exhaust: M22x1,5
  • Flow L M: 4100 l/min
  • Housing Material: Aluminum, Polyamide fiber-glass reinforced
  • Industry: Industrial
  • Max Working Pressure: 16 bar
  • Min Working Pressure: -0.95 bar
  • Seat Seal Type: Soft seal
  • Dimension: 7.87x3.15x1.97 (inches)
View other configurations.
AVENTICS 5/2-directional valve, Series CD12 R412013344
