Aventics R481654445 Pneumatic Linear Actuator

multi-position cylinder, Standard cylinders, ISO cylinder, Piston rod cylinders, Compact cylinder, ISO 21287. View other configurations.

Aventics R481654445 Pneumatic Linear Actuator — Aventics-R481654445

Call for pricing

Part Numbers

R481654445
R481654445

Highlights...

R481654445
By Aventics
FREE Shipping on orders of $1,000 or more
Call for availability

Features

Bore Size: 20 mm
Compressed air connection: M5
Cushioning: Pneumatic pre-adjusted cushioning
Cylinder Function: Double-acting
Environmental requirements: Industry standard, ATEX optional
Industry: Industrial
Magnetic piston: Piston with magnet
Max Working Pressure: 10 bar
Piston force extending: 198 N
Piston force retracting: 148 N
Piston rod modification: single
Piston rod thread: M8x1,25
Piston rod thread type: External thread
Scraper Type: Standard Industry Scraper
Stroke Length: 15 mm

View other configurations.

AVENTICS Compact cylinder ISO 21287, Series CCI R481654445
